Digital stainless steel hot plate is equipped with dual-direction temperature regulation and precise temperature control. It is an essential laboratory device for scientific research and education in biology, microbiology, genetics, medical science, and environmental protection. Widely used for low-temperature constant temperature tests, cultivation experiments, environmental tests, etc.
I. Main Features
- Stainless steel working panel with excellent corrosion resistance.
- Aluminum heating plate with high thermal conductivity, fast heating, and uniform temperature.
- Original Yudian PID intelligent digital temperature controller, high precision, easy and safe operation.
- High-quality SSR solid state relay, service life is 100 times longer than ordinary relays.
- Fast and uniform heating, simple operation, over-temperature alarm for safe use.
- Special forming process ensures no deformation at high temperature.
- Whole body made of SUS304 stainless steel, no rust, no paint peeling.
- Built-in cooling fan and vents protect internal components from overheating.
- Fast temperature rise, low power loss, excellent temperature uniformity.
- Multiple high-grade stainless steel heating tubes for easy maintenance and low failure rate.
II. Technical Parameters
Model: ET-2020-SS
- Power Supply: AC220V 50Hz
- Heating Power: 1500W
- Working Area: 200×200mm
III. Applications
- Laboratory heating, temperature testing (biology, medical, environmental, biochemical, research labs).
- LED industry: aluminum substrate & lamp soldering & repair.
- LCD & mobile screen repair, cable removal, touch screen glue removal.
- Industrial sample baking, drying, constant temperature heating.
- Electronic components preheating, SMD rework & repair.
IV. Operation & Maintenance
- Power socket must be properly grounded for safety.
- Keep the working surface clean before and after use; no water or dirt allowed.
- Place test tubes or containers before heating to avoid cracking.
- Connect power and turn on the switch; the indicator lights up when working.
- Do not touch the hot surface during operation. Supervision is required.
- Cut off the power after use.
Factory & Service
15+ years professional manufacturer of stainless steel hot plates. Customization available according to customer requirements. Large stock, fast quotation. Welcome to inquire!
